As mentioned in a previous blog post about PVC pipe outer diameter, PVC pipe and fittings use a nominal system for standard sizing. This is so all parts with the same size in their name will be compatible with each other.

What is a union used for in plumbing?

Pipe unions connect two pipes together in a way that requires only one pipe to be turned when removing the union, facilitating repairs. Pipe unions also prevent galvanic corrosion when connecting pipes of dissimilar metals.

What is a tee in plumbing?

Pipe tee fitting is a fitting that has a T shape. It has two outlets at an angle of 90° each and one main connection line. It is a pipe that has adjacent outlets and used to connect pipes at 90° angle. Pipe tee fittings are used for commercial as well as industrial applications.

What is the difference between elbow and bend?

Bend has a larger radius than elbows. Generally, the most basic difference is the radius of curvature. Elbows generally have a radius of curvature between one to twice the diameter of the pipe. Bends have a radius of curvature more than twice the diameter.

Do pipe unions have a flow direction?

RE: Flow Direction Through a Pipe Union In some applications, it is common to flow from the nut side to the external thread side, but this is not required. There are also applications where it may make sense to flow the other direction.

What is street elbow used for?

A street elbow (sometimes called a street ell or service ell) is a type of plumbing or piping fitting intended to join a piece of pipe and another fitting at an angle.

What is a PVC union?

PVC unions and PVC pipe union connectors are pipe fittings designed to connect two pipes together without the use of a sealant or traditional glued coupling. … This means that wherever you use a PVC union to connect pipes together these pipes can be disconnected and worked on with relative ease.

How long will a PVC union last?

This entry was posted on January 9, 2020 by Korey Kashmer. As one of the most-used plumbing materials, PVC pipe is known for being very durable and long-lasting. In fact, PVC pipes last approximately 100 years.

Are PVC Unions water tight?

On their own, without any type of adhesives or lubricants, PVC fittings will fit fairly snugly. That being said, the connection between the pipe and the fitting will not be watertight.

Where can you use a union on a drainage system?

Unions are used on piping systems, including plumbing, that have soldered, brazed, welded, solvent welded, or threaded connections. Unions are used at fixture and equipment connections and to effect repairs and tie-ins for adding to an existing piping system. Unions should not be installed in inaccessible locations.

Article first time published on

Are pipe unions interchangeable?

Union’s are not compatible. Unlike the pipe side, the mated side of a union is not standardized. Even if the threads are the same (as there are only so many available) the mating surface may not be.

What does a pipe union look like?

A pipe union consists of three parts – a nut, a female end and a male end. To make an effectively working pipe fitting, both the male and female ends are sealed together with the help of nuts. A female threaded fitting has threads on the inside, while in the male-threaded fitting, the threads are on the outside.

Why is a street 90 called a street 90?

when water mains were being run down a street, the installers would put a tee in front of a house. the branch of the tee was facing up. into the branch they would put an elbow with male threads on one end and female threads on the other. so it was known as a “street” elbow.

What is difference between duct and pipe?

The main difference in pipes & ducts is their fabrication process. Pipes are generally made of flat long rectangular sheet welded in round shape and is open at both ends. Whereas, ducts are made of galvanized steel and are often insulated. Ducts are used to exchange hot & cold fluids mainly gases.

What is the difference between a 3R and a 3D elbow?

What is the difference between a 3R and a 3D elbow? There is no difference. Both have a centerline radius of three times the nominal size. MSS SP75 calls them 3R rather than 3D as usually associated with bend radii.

Can you lay a sanitary tee on its back?

When you are using a sanitary tee, you should not lay it on its back with a side opening because this will result in an upstream splash of waste when it hits the bottom of the horizontal pipe. This will create clogging inside the line.

What is a clean out plug?

A cleanout plug is a cap or lid used to close off a drain cleanout pipe. … Beneath the cover of these drains, there is a standard drainage pipe as well as a metal or plastic cap situated off to one side of the pipe. This cap covers the pipe cleanout, and prevents waste water from entering the cleanout.

What is plug in plumbing?

Plug is a component of plumbing component which is generally used to close pipe opening during inspections and repairs. Plug are generally contains male threads.

What is a union nut?

In contrast to a coupling requiring solvent welding, soldering, or rotation (for threaded couplings), a union allows easy connection and disconnection, multiple times if needed. It consists of three parts: a nut, a female end and a male end.

What is a union joint?

a detachable joint, formed by means of a union, that is used to connect the parts of a piping system to various tanks or machines. Besides a union, a union joint consists of a gasket, a locknut, and a reducer, such as an elbow or a coupling (Figure 1).

What is union pipe?

Pipe Union. Pipe Union is a type of fitting equipment designed in such a way to unite two pipes which can be detached without causing any deformation to the pipes. … In other words, the pipe unions can disjoint two pipes very easily. They are widely demanded in the pipe fitting market.

Is there a proper way to install a union?

Thread the male half of the union nut onto the left-side pipe, and tighten it securely. Slip the ring nut portion of the union onto the right-side pipe with the threads facing outward. Thread on the other half of the union nut, and tighten it securely.

What is a PVC slip joint?

PVC waste pipes began to replace metal waste pipes in the home starting in the 1970s. … A slip joint allows for a quicker connection of two different types of waste pipe. You can even use a slip joint to connect metal waste pipe systems with a PVC sink drain.

What is a solvent Union?

PrevNext. Unions are used anywhere in your plumbing system where a disconnect is required. These may be white or gray depending on our supplier.

Are PVC unions reliable?

Plastic piping and threaded fittings are extremely reliable at providing a leak free service. Issues with stress cracking of PVC threaded fittings can be easily avoided by adhering to proper installation guidelines.

What is PVC elbow?

PVC elbow is designed to turn the flow of a liquid. This allows for the configuration of a piping system to fit in an existing location. Often in home plumbing, for example, the plumbing needs to turn to flow where it is needed to avoid existing structures in the home or access outside lines.

What does no hub mean in plumbing?

Intended for use with DWV systems, no-hub couplings are used to join cast iron soil pipe that does not have the traditional Hub and Spigot. They are normally installed using a torque wrench. Generally, they have more clamps and provide a greater band load than standard no-hub couplings.

What is a 90 degree elbow?

An Elbow is used to change the direction in piping and is also sometimes called a “quarter bend”. A 90 degree elbow attaches readily to plastic, copper, cast iron, steel and lead. … The main application area of an elbow (90 degree) is to connect hoses to valves, water pressure pumps, and deck drains.

Should you use Teflon tape on PVC fittings?

Don’t use Teflon tape, Teflon paste or pipe dope. … Teflon paste and pipe dope, just like Teflon tape, make threaded joints slippery. Their use on PVC fittings can be an invitation to over-torque. When working with threaded plastic fittings do use a proper sealant.

Do you use Teflon tape on water supply lines?

Most faucets will have hot and cold water supply lines attached, so you just need to connect them to the appropriate water supply line. You may need to use Teflon tape (aka plumber’s tape) for this part, which is used to seal and lubricate threaded pipe joints.

How far does PVC go into fitting?

For a good interference fit, the pipe should easily slip into the fitting 1/3 to 2/3 of the way. Too tight of a fit is not acceptable because the pipe may not be able to bottom into fitting during assembly.
