When it comes to an optimal SHGC rating, again you will want to look for a rating of 0.25 or less for efficient energy performance and lower A/C costs. Although for people that like their home on the warmer side should choose a SHGC rating between 0.35-0.60 to allow natural solar heat in.

What is a good U-factor and SHGC for windows?

While the U-Factor can take any value, in general for windows it ranges from 0.20 to 1.20. The lower the U-Factor, the better the window insulates. The SHGC measures how much of the sun’s heat comes through the window. It can range in value from 0 to 1.

Do you want high or low SHGC?

What is SHGC? SHGC is short for solar heat gain coefficient, a number that represents the amount of solar radiation through a window. It’s measured between 0 and 1; a lower number means less solar heat transfer. Though low glass-only SHGC is good, it’s better to have a lower whole window SHGC for optimal heat balance.

Is a higher U-factor better?

The U-Factor tells you how adequate your windows are at insulation. It’s expressed in Btu/h·ft²·°F and the range is 0.25 to 1.25. The higher your U-Factor rating, the better, as that means your windows are well-insulated.

How can I increase my SHGC?

SHGC and U-factor can be reduced in the glass portion of a window assembly in a number of ways: Low-emissivity (low-e) coatings reduce the ultraviolet and infrared light that passes through the glass, limiting heat gain while preserving visible light transmission.

What windows have the highest R value?

Triple-pane windows have a higher R value because they use all the performance features mentioned above, such as low-E, plus three layers of glazing instead of the typical two layers. Adding a third pane of glass improves efficiency but makes them bulky, heavy, and expensive.

Is a factor of .30 good?

The “30/30” rule is common: U-factors of under 0.30 (which is good) are often paired with SHGC’s of under 0.30. That’s a good target for the South.

What is the SHGC value of glass?

Glass with a low SHGC is best used in areas of direct sunlight, for example to reduce the amount of heat coming through the windows in summer. For example, our 4mm clear float glass has an SHGC of 0.85, whilst ComfortPlus™ has an SHGC between 0.57 and 0.60 depending on the colour.

What do low-E windows do?

Low-E coatings have been developed to minimize the amount of ultraviolet and infrared light that can pass through glass without compromising the amount of visible light that is transmitted. When heat or light energy is absorbed by glass, it is either shifted away by moving air or re-radiated by the glass surface.

What are good U-values?

The best insulating materials have a U-value of close to zero – the lower the better. Building regulations currently stipulate that for a new building, the elements must have maximum U-values as follows: Wall – 0.3 W/m2k. Roof – 0.15 W/m2k.

Article first time published on

What is the difference between U-value and U-factor?

U-value (also known as U-factor) is a measure of heat transfer (heat gain or loss through glass), while R-value is a measure of heat resistance. U-value is not a material rating; it is a calculation of the conduction properties of various materials used in the construction of windows, doors and skylights.

How can I lower my SHGC?

There are several ways that SHGC can be reduced, including outside shading such as pergolas, Venetian blinds, trees, and bushes, etc. Other ways that SHGC can be reduced are Low-e coatings.

What is LSG glass?

Light to solar gain (LSG) is the ratio of the visible light transmittance (VLT) and solar heat gain coefficient (SHGC) of a glass. In absolute percentage terms, a ratio greater than 1 signifies that the daylight passing through the glass is more than the sun’s direct heat passing through it.

What is the SHGC of low-E glass?

With a glass U-Factor of just 0.26 and an SHGC of 0.69, Low-E 180 Glass is an excellent basic product for passive solar applications. By blocking heat loss to the outside of the glass, the high solar gain glass keeps homes warm in winter and cool in summer.

Does low-e window film work?

84 or 84%. Low-E films have lower “e-values” than run of the mill solar control films which is why they work best for savings through energy-efficiency. These films reduce heat loss in winter but also reduces heat gain in the summer–making them the clear choice for year-round savings.

Can I add low-e coating to windows?

If you aren’t prepared to replace your old windows with new, energy-efficient windows that feature factory-applied low-E coatings, applying low-E film can be a viable, cost-saving alternative. Applying low-E film can be a do-it-yourself project if you have small windows.

Can you apply low-e coating to windows?

Low-E coatings can be applied to both the exterior and interior glass surfaces of a window or door and deliver comfort and energy savings in both directions. On an exterior glass surface, a Low-E coating can reflect the heat of the summer sun or the cold of winter away from the home.

How are windows rated?

Energy Performance Ratings U-Factor ratings for windows generally fall between 0.20 and 1.20. The lower the U-value, the greater a window’s resistance to heat flow and the better its insulating value. (The window’s insulating value is indicated by the R-value, which is the inverse of the U-value.)

What is window UF?

The transmittance value of the frame, Uf, is a fictitious value, that is functional to the “architecture” of the overall energy calculation. … This shows how the thermal transmittance of a window depends on its total heat flow, L2D_f, given by the width of the frame, bf, and its transmittance value, Uf.

What U-value do I need for windows?

Generally, the lower the U-Value of a window the better. Low U-Values indicate that a window will perform well in maintaining the indoor temperature of a customer’s home. Recently building regulations have changed, meaning that new windows must have a u-Value below 1.6 W/m2k.

What is a good ER rating for windows?

A single number, or measurement, is established using complex scientific calculations and computer modeling. Basically, the higher the number, the more energy efficient the window or door is. The range for most Energy Star approved windows is between 25 and 35 ER points.

Are triple pane windows worth?

The bottom line is this – triple pane windows are worth the additional cost if you plan on living in your house for anywhere from fifteen to twenty-five more years. … Triple-pane windows can be up to 20% more efficient than double-pane windows and up to 50 percent more efficient than single-pane windows.

Are triple pane windows a gimmick?

Triple Pane Windows are not a gimmick, but they are a luxury. They aren’t the standard for new construction starts in most of the country and their expense, weight, and their installation are some of the reasons. The difference between triple-pane and dual pane windows is in the number and fabrication of the windows.

What is Planitherm glass?

Planitherm is thermally insulated glass. It uses the latest advances in glazing technology to coat the surface of the glass with a high performance thermally insulating layer, and this will, of course, lead to savings in heating bills for your home. It´s known as low-emissivity glass, or low-E glass, for short.

What is coated glass?

Coated glass is an industrial glass product onto which metal oxides are sprayed in the form of thin coatings (0.01 µm to 0.8 µm). … It modifies the behavior of the glass with respect to solar radiation, in the visible and infrared domains. On distinguishes between pyrolitic and magnetron coatings.

What does argon gas do for windows?

Because argon gas is denser than air, adding it to the glass unit in double-pane windows improves thermal insulation efficiency. Used in conjunction with a special low-E (short for low emissivity) glass coating, argon gas windows bring the temperature of the window closer to room temperature.

How do I convert SHGC to SC?

Use the formula SHGC = SC*0.87 to convert between SHGC and SC. Enter the value that you have and solve algebraically to calculate the value that you don’t have. Multiply SHGC by 1.15 to convert the value from SHGC to SC.

Is a lower W m2K better?

A material’s thermal conductivity is the number of Watts conducted per metre thickness of the material, per degree of temperature difference between one side and the other (W/mK). As a rule of thumb, the lower the thermal conductivity the better, because the material conducts less heat energy.

What is the U-value of a wall?

England. * A U-value of 0.55 W/m²·K is used for cavity insulation and 0.30 W/m²·K for internal or external wall insulation.

How do you get the 0.18 U-value wall?

To meet 0.18 W/m2K, cavity walls will need either a full-fill cavity, additional internal insulation or have a cavity greater than 100 mm.

Why use u-value instead of R-value?

While U-value is used to measure the performance assemblies such as IGUs, R-value is used to measure the performance of most other parts of the building envelope, such as walls, floors and roofs. … Thus, while lower U-values indicate better insulating performance, higher R-values indicate better thermal resistance.
