: a pump for raising or circulating water.

What is the use of water pumps?

Water pumps are machines for moving water, they play a fundamental part in agriculture as they move water from its source to the fields and crops. Water pumps can be used with many forms of irrigation, such as drip, sprinklers or with a hose.

How many types of water pumps are there?

There are two basic types of water pumps: centrifugal and positive displacement. Both types are designed to move water from one place to another continuously. A centrifugal water pump uses a rotating impeller to move water into the pump and pressurize the discharge flow.

How is water pump works?

All pumps use basic forces of nature to move a liquid. As the moving pump part (impeller, vane, piston diaphragm,etc.) begins to move, air is pushed out of the way. The movement of air creates a partial vacuum (low pressure) which can be filled up by more air, or in the case of water pumps, water.

What are the parts of pump?

The main components in a pump are the casing, impeller, backing plate, shaft and shaft seal, and the motor adapter. Some pumps have the backing plate as part of the casing in which case you would have a removable cover. The shaft seals are a critical part of the pump and selecting the right seal is an important step.

Which water pump is best?

1. Havells Hi-Flow MX2 Series 0.5 HP Centrifugal Water Pump. …
2. Havells Hi-Flow MX2 Series 0.5 HP Centrifugal Water Pump. …
3. Kirloskar 40S Mini Water Pump.
4. Crompton 0.5HP SP Aquagold 50 Water Pump. …
5. Kirloskar KOSi-135 5 Star HP Openwell Submersible Pump.

What are the 4 types of pumps?

• 1). Centrifugal Pumps. These types of pumps are most commonly used worldwide. …
• 2). Vertical Centrifugal Pumps. …
• 3). Horizontal Centrifugal Pumps. …
• 4). Submersible Pumps. …
• 5). Fire Hydrant Systems. …
• 1). Diaphragm Pumps. …
• 2). Gear Pumps. …
• 3). Peristaltic Pumps.

What are the 7 major parts of a water pump?

A water pump has several small parts that join together to make one working machine. The most basic components include the hub/pulley, bearing, body/house, seal, and impeller.

What are the 2 main classification of pumps?

Pumps are divided into 2 major categories: Dynamic and Positive Displacement (aka Displacement).

What is pump housing?

Pump casings serve to seal off the intside of the pump to atmosphere to prevent leakage and retain pressure. In the case of centrifugal pumps, they surround the pump rotor which transmits energy to the fluid handled via the impeller(s) mounted on the rotating shaft.

Article first time published on

What do you mean by impeller?

An impeller is a part of a pump or compressor that rotates at a high speed and acts as a propeller to increase a fluid’s pressure and flow rate. Impellers are made from various metals such as steel, iron or bronze, as well as plastics.

What is the material of water pump?

The pump casing is made of duplex stainless steel (50% ferrite + 50% austenite). As the strength of cast steel becomes higher, usually when the pressure is greater than 16Mpa, the pressure-bearing parts are mostly cast steel. The national standard code is ZG, and the most commonly used grade is ZG230-450.

Which pump is used for irrigation?

Volute pumps are widely used in irrigation. They are of simple construction, the only moving parts being the impeller and shaft. The impeller is housed in a casing (volute). The volute pump most often used for irrigation purposes is the (radial-flow) centrifugal pump.

Which pump is used in homes?

Pedestal Sump PumpsSubmersible Sump PumpsPool PumpsPedestal pumps are positioned with the pump motor out of the water and above the sump basin.Submersible sump pumps are put underwater in your sump pump basin.Water pumps send water through the filter, heater and chlorinator.

What is pump efficiency?

Pump efficiency (η) is the product of mechanical (ηm) and internal efficiency (ηi). The best pump efficiency (ηopt) is the highest efficiency for the rotational speed and fluid handled as specified in the delivery contract.

Why vertical pumps are used?

Pros of Vertical Centrifugal Pumps Smaller footprint when compared with horizontal pumps. Suitable for applications that have restricted surface area. The NPSH can be altered thereby making it suitable for a wide range of applications. Suitable for liquids with high pressures and high temperatures.

How many watts is a water pump?

A typical water pump’s wattage can vary between 250 watts to 1,100 watts. Take the wattage of the specific water pump and multiply it times how many hours a day it runs. Then, multiply it by how many days a year it runs, and divide by 1000.

What is the difference between 0.5 HP and 1Hp water pump?

For example if an 0.5 HP motor with discharge rate of 200 litres per hour takes 2 hours to lift the water, then an 1 HP pump with higher discharge rate 400 litres per hour can complete the task in less than 1 hour.

What is pump inverter?

Put simply, it is an inverter that is controlling a pump’s motor. There are several reasons why you might want to use an inverter on your pump: To save energy/costs. To prevent costly maintenance and down time.

Which pump is used for high pressure?

Multi-stage centrifugal pumps tend to be used for applications that require higher pressure or pressure head. Diaphragm type pumps are generally deployed within the following ranges: Flow rate ranges between 20 to 750,000 lpm.

What is the type of pump?

SUB-TYPEEXAMPLESReciprocating PumpBladder Diaphragm Peristaltic Piston / plungerRotary PumpGear Screw Progressing cavity Rotary lobe Rotary vane

What is pump Slideshare?

Pump A pump is a device used to move fluids, such as liquids, gases or slurries. It increases the mechanical energy of the fluid. The additional energy can be used to increase –  Velocity (flow rate)  Pressure  Elevation.

What is priming in pump?

What is pump priming? Priming simply means preparing or getting something ready for operation. For a centrifugal pump to work properly, you need to fill it up with water. … The pump will resume operation once the air is removed.

What is difference between reciprocating and centrifugal pump?

The main differences between Centrifugal Pump and Reciprocating Pump are the Centrifugal pump works low medium pressure head and Reciprocating Pump works high medium pressure head.

What is centrifugal pump with diagram?

The working principle of a centrifugal pump is based on forced vortex flow. The forced vortex flow means that when a certain mass of fluid rotates by an external force (leading to an external torque), there is an increase in the pressure head of the liquid.

What is pump casting?

Pump Casting A pump is a mechanical device that moves fluids (liquids or gases, slurries.). We are one of Pump Castings manufacturers and specialists in China. We can produce any pump castings or cast pump parts in our foundry.

What is a impeller water pump?

An impeller is a rotating iron or steel disc with vanes in a centrifugal pump. Impellers transfer energy from the motor that drives the pump to the fluid being pumped by accelerating the fluid radially outwards from the centre of rotation. … Impellers are available as vortex or channel impellers.

What is the function of impeller in pump?

An impeller is a rotating component of a centrifugal pump that accelerates fluid outward from the center of rotation, thus transferring energy from the motor that drives the pump to the fluid being pumped.

What is difference between propeller and impeller?

A propeller is a type of fan that propels fluid by pushing against it, converting rotational force into a linear motion. An impeller is a type of rotor that is typically part of a pump and creates a sucking force, i.e. drawing liquid into a vehicle or engine.

What is a pump rotor?

Helical Rotor Pumps are a sturdy and robust category of Positive Displacement Pumps. … The rotor is fitted inside the stator which is lined with rubber. The rotor rotating inside the stator forms cavities via which media is pumped from suction to the discharge end of the pump.

What is impeller and its types?

The impeller is the rotating component within the centrifugal pump design, which transfers the energy from the pump’s motor to the fluid. … There are several types of impeller, each of which offer different performance characteristics that make it more or less suitable than the others for a particular application.
