Tenon length: The general rule is that the minimum tenon length is five times its thickness. So a 1/4″-thick tenon should be 1-1/4″ long. Of course, if you look at antique furniture, you see this “rule” violated , or maybe the furniture was made before they made the rule.

What size should a tenon be?

A: Of course, the specific mortise-and-tenon size will vary by application, Michael. But as a general guideline, make the tenon about 1⁄ 3 the total thickness of the tenoned workpiece, and about 1⁄ 2 – 2⁄ 3 as long as the width of the mortised workpiece.

How do you measure mortise and tenon?

With the tenon, mark the length of the tenon around the four sides and scribe the thickness of the tenon on the sides and end. To mark the thickness of the tenon, measure the thickness of tenon rail, divide this by three and set a mortise gauge (right) to that measurement.

What size should a mortise be?

Cutting the Mortise. The mortise depth should be roughly three times the thickness of the tenon. It can be cut in several ways, among them the traditional approach of using sturdy mortising chisels and a mallet to chisel out the hole by hand.

How do you cut a perfect tenon?

1. Once you’re set up, cutting the tenons goes quickly. The tenon cheeks are cut first. …
2. The dado blade often leaves small ridges on the tenon cheek. …
3. Once all the tenon cheeks have been cut and smoothed, you complete the tenons by cutting the top and bottom shoulders.

Is the mortise or tenon cut first?

To make a mortise and tenon joint, always cut the mortise first because it’s much easier to cut the tenon to fit an existing mortise than the other way around.

What is a blind tenon?

blind-mortise-and-tenon joint, stub mortise and tenon A joint combining a blind mortise and a stub tenon; neither is visible in the assembled joint.

What is blind mortise and tenon?

A stopped (blind) mortise-and-tenon joint is one in which the tenon is hidden fully in the mortise (see Figure 2). This type of tenon is often used on table and chair legs or anywhere else that you don’t want to see the joint. Figure 2: A stopped mortise-and-tenon joint is commonly used for chair and table legs.

How does a mortise gauge work?

A mortise gauge or mortice gauge is a woodworking tool used by a carpenter or joiner to scribe mortise and tenon joints on wood prior to cutting. … It has two protruding pins, often called “spurs”, which are designed to scribe parallel lines marking both sides of a mortise at the same time.

What are the 3 types of mortise and tenon joints?

Types of mortises and tenons Open mortise. Stub mortise. Through mortise. Through-wedged half-dovetail.

Article first time published on

What is mortise and tenon construction?

Mortise and tenon joinery is a woodworking joining technique that has been used for centuries. … The tenon on one piece of wood is shaped to fit inside a mortise (hole). By making the two pieces fit tightly together with strong waterproof wood glue, the joint becomes incredibly strong.

Can you use a mortise bit in a hand drill?

Pro Tip: Don’t attempt to use a mortising bit in a handheld power drill. We’ve tried it…and it doesn’t work. If you attempt to use a mortising bit in your drill press, you’re going to need to retrofit your machine quite a bit.

How do you cut a fence post into a mortise?

1. Lay out the desired location of the mortise opening on the side of the fence post. …
2. Cut the perimeter line of the mortise using a wood chisel. …
3. Chip out the interior area of the mortise outline, cutting toward the inside and pivoting the chisel to remove the wood chips.

What is the strongest wood joint?

Mortise and Tenon Woodworking Joints One of the strongest woodworking joints is the mortise and tenon joint. This joint is simple and strong. Woodworkers have used it for many years.

What does the PVA stand for in PVA glue?

Here’s what it says about PVA: … Polyvinyl acetate is a component of a widely used glue type, commonly referred to as wood glue, white glue, carpenter’s glue, school glue, Elmer’s glue (in the US), or PVA glue.”

Which is stronger screws or dowels?

Dowel joinery is stronger than screw joinery. The increased glue surface caused by the glue deeply penetrating the wood gives the dowel more holding power. … Dowels also have superior holding power in modern composite materials such as particleboard and plywood.

What is a cutting gauge?

Cutting Gauges are like marking gauges, except they use a knife instead of a pin. They’re used for scoring across the grain and can also be used for cutting strips of wood veneer and small rebates. The cutter is secured in place with a brass wedge, which also enables removal for sharpening the cutter.

How do you measure a tenon?

Over time craftsman have developed general rules for properly sizing their mortise and tenon joints, they are: Tenon length: A tenon’s length should be at least five times its thickness. So, a 1/4″-thick tenon should be 1-1/4″ long.

What does a marking gauge look like?

A marking gauge is the most common type of gauge used for marking. It uses a small pin, sometimes referred to as a spur, to mark the wood when the tool is dragged across it. In its early form, the marking gauge was simply two pieces of wood attached together with a pin through one end for marking.

How is a marking gauge used?

A marking gauge is used in woodworking to mark out lines for cutting or other purposes. The main purpose is to scribe a line parallel to a reference edge.

Do you need a marking gauge?

Pencils have always been vital to woodworkers, but so are marking gauges for precision results. Marking gauges are indispensable for joinery work such as cutting dovetails and mortise-and-tenon joints.

What is a mortise saw?

A mortiser or morticer is a specialized woodworking machine used to cut square or rectangular holes in a piece of lumber (timber), such as a mortise in a mortise and tenon joint.

Can you cut a mortise with a table saw?

Using a table saw solves all these problems. To create the mortise, you make the leg out of two separate pieces. Then, instead of making the mortise after the leg is glued up, you cut dadoes on the inside face of both halves of the leg first (detail ‘a’).
