The 2017 National Electrical Code (NEC) requires the protection of an arc fault circuit interrupter (AFCI) for 15 and 20 amp circuits in all newly built residential areas, but they are not needed in bathrooms, garages, or outdoor areas.

Where are arc fault breakers not required?

AFCI protection is not required for outlets located outside or in garages or bathroom areas. (B) All 15A or 20A, 120V branch circuits supplying outlets in dormitory unit bedrooms, living rooms, hallways, closets, bathrooms, or similar areas.

What rooms need to be on arc fault breakers?

As of the 2014 NEC, AFCI protection is required on all branch circuits supplying outlets or devices installed in dwelling unit kitchens, along with the 2008 NEC additions of family rooms, dining rooms, living rooms, parlors, libraries, dens, bedrooms, sunrooms, recreation rooms, closets, hallways, laundry areas, and …

Where are arc fault breakers not required 2020?

As long as branch circuits are not extended more than 6 feet, AFCI protection is not required. In the 2020 NEC, a public input (code change proposal) was accepted to clarify “6 feet”.

Do garage lights need to be AFCI protected?

The shorter list is areas not requiring AFCI protection: unfinished basement areas, attached or detached garages, outdoor lighting and receptacles, accessory buildings and bathrooms are not required to be fed via AFCI protected circuit.

Can I use AFCI outlet instead of breaker?

Why would I use AFCI outlet instead of breaker? The AFCI outlet can be a great alternative depending on the circumstance. AFCI outlets work with any type of wiring and are not dependent on the type of breaker in the panel.

Does refrigerator require AFCI?

A modern refrigerator requires a dedicated 20-amp circuit. … This circuit usually does not require GFCI protection unless the outlet is within 6 feet of a sink or located in a garage or basement, but it generally does require AFCI protection.

Are arc fault breakers required in older homes?

AFCIs have proven so effective at preventing electrical fires that the National Electrical Code (NEC) requires AFCIs to be installed in almost every room in newly built houses. … The NEC also requires the installation of AFCIs in existing homes whenever an addition, an extra circuit, or even an extra outlet is added.

Does a washing machine need to be on an arc fault breaker?

Nearly every room/ area in a dwelling unit requires AFCI protection, so no matter where you put a clothes washer, it will be AFCI protected in a newer home. … As always, refer to the manufacturer’s installation instructions regarding AFCI requirements for the installation of your new clothes washing machine.

Do kitchens require AFCI?

The latest National Electrical Code requires both AFCI and GFCI protection only in kitchens and laundry rooms. And within those rooms, the Dual Function AFCI/GFCI Receptacle provides what is called “feed-through” protection, which means it provides protection for all wiring and extensions attached to the load side.

Article first time published on

Are GFCI outlets required in garage?

GFCI protection is required for 125-volt to 250-volt receptacles supplied by single-phase branch circuits rated 150 volts or less to the ground. GFCI receptacles are required in bathrooms, garages, crawl spaces, basements, laundry rooms and areas where a water source is present.

Should garage door openers be GFCI protected?

Yes, a garage door opener must have GFCI protection.

Do garage lights have to be GFCI?

3 Answers. NEC 210.8. 2 requires all outlets in a garage to be GFCI protected so if your lights are connected by an outlet they need GFCI protection if they are hard wired they do not require GFCI protection.

Does microwave require AFCI?

A dedicated 20-amp circuit is needed to feed the microwave oven. Since the appliance is plugged into an outlet, AFCI protection is required.

Should a garage refrigerator be on a GFCI?

A. That “protector outlet” you’re referring to is a GFCI, or “Ground Fault Circuit Interrupter” receptacle, and GFCI’s are required by building code in garages, kitchens, bathrooms, and on the exterior of new homes. … So freezers and refrigerators should never be plugged into GFCI’s.

Can a dishwasher and fridge be on the same circuit?

If you can meet the provisions in 210.52, and still end up under the load calculations in other parts of the code. AND the dishwasher is cord-and-plug connected, then it is possible to have the fridge and dishwasher on the same 20 ampere small appliance branch circuit.

Do all outlets need AFCI?

AFCIs are required on all 120-volt, single-phase circuits with 15 to 20 amps supplying receptacles in all dwelling rooms. If, for example, if you use your basement as a living room, playroom, or recreational room, then you will need to install an AFCI protection. However, basements (garages, attics, etc.)

Why are AFCI breakers so expensive?

Poorly installed electronics (such as a ceiling fan) can cause your newly installed AFCI breaker to constantly trip. If this is the case, the electrician will need to fix the faulty wiring in order for the AFCI breaker to work properly and this will increase your overall cost.

Do AFCI outlets protect the whole circuit?

An AFCI device protects the entire circuit from the electrical panel through the downstream wire to the outlet, along with all appliances and equipment plugged into that circuit. If an AFCI device trips, it is most likely the result of a potentially dangerous arcing condition detected by the device.

Can you put a GFCI outlet on an AFCI circuit?

The 2008 National Electrical Code (NEC) requires AFCI breakers in nearly all new construction. … They will not interfere with the operation of ground fault circuit interrupter (GFCI) outlets, so it’s safe to install AFCIs on circuits that include GFCI outlets.

Does dryer require AFCI?

No — the 2014 NEC only calls out AFCIs for 120V, 15 and 20A outlets — the dryer is 240V, so it doesn’t need an AFCI. 210.12 Arc-Fault Circuit-Interrupter Protection.

Can you have a GFCI receptacle on a GFCI breaker?

Yes, it can be done. There is no problem having a GFI fed from another GFI.

What year did arc fault breakers become required?

In 1999, AFCIs became a requirement in the National Electrical Code (NEC®). An AFCI breaker provides a higher level of protection than a standard circuit breaker by detecting and stopping a hazardous arcing condition before it can become an electrical fire.

Does a furnace require AFCI?

Yes, you need AFCI protection As of the 2017 NEC, AFCI protection has been extended to all 15 and 20A, 120V branch circuit outlets in all dwelling unit locations. This includes dedicated appliances such as furnaces and dishwashers, and even smoke detector circuits.

When did GFCI become required in garage?

Receptacles in the garage were first required to be GFCI-protected by the 1978 edition of the National Electrical Code (NEC).

Why does my garage GFCI keep tripping?

Circuit overload occurs when more amperage flows through an electric wire or circuit than it can handle. This may happen if you connect malfunctioning or defective appliances. Loose, corroded wires or connections may also be to blame. Once the GFCI outlet senses an overload, it trips or “breaks” the circuit.

What is the code for garage outlets?

However, the code is just a minimum set of installation rules. The basic rule for garage receptacles is that one receptacle outlet needs to be installed in each vehicle bay and not more than 5 ½ feet above the floor.

Do garage door openers have to be on their own circuit?

No, a garage door opener is not required to be on a separate, dedicated circuit. But, the ceiling receptacle outlet that it’s plugged into must be GFCI-protected. … Usually the garage door opener is on the same circuit as the garage wall receptacles and one of them is GFCI.

Do garage door openers have to be on a separate circuit?

Is a dedicated circuit necessary for a garage door opener? A separate circuit is not required for a garage door opener, but it cannot be plugged into an electrical outlet via an extension cord. The unit needs a new outlet.

Is there a difference between GFI and GFCI?

GFCI vs GFI. Ground fault circuit interrupters (GFCI) and ground fault interrupters (GFI) are the exact same device under slightly different names. Though GFCI is more commonly used than GFI, the terms are interchangeable.

How do I find a GFCI outlet in my garage?

1. Go to the kitchen, bathroom, garage, crawl spaces, unfinished basement and outdoor outlets and plug in the outlet tester. …
2. Locate the breaker box. …
3. Search for any GFCI outlets. …
4. Press the test button to deactivate any outlets loading off the GFCI unit.
