Gas piping shall not be used as a grounding conductor or electrode. protection system is installed, the bonding of the gas piping shall be in accordance with NFPA 780, Standard for the Installation of Lightning Protection Systems, 2008.

Can you run a ground to a gas line?

In summary, you cannot use a metal underground gas piping system as a grounding electrode. However, you must bond the piping system to the grounding electrode system for safety reasons.

Can electrical panel be grounded to gas line?

Bonding electrical panel to gas line ? Yes sir. The gas line was already bonded by the EGC run in the circuit feeding the furnace. Some areas require an additional bond.

Should a gas pipe be earthed?

2 Answers from MyBuilder Gas Engineers The main earth bonding for the gas pipe should be done after the gas meter in 10mm bonding and not more the 60cm or after 1st tee off. The cross bonding under the boiler should connect all pipework and be done in 4mm bonding.

Can you ground a gas line to a ground rod?

ANSWER: Yes, I said metal gas piping should be bonded to the supply system grounded conductor. … Section 250-104(b) does require that metal gas piping should be bonded to the grounding electrode system. This can be done by terminating at the neutral bar, or any of the electrodes in the grounding electrode system.

Why are gas pipes earthed?

What is protective bonding? Protective bonding reduces the risk of life-threatening electric shocks and electrical fires in your home. It’s typically needed in older buildings where gas and water pipes are made from metal rather than plastic.

Does black gas pipe need to be grounded?

3 Answers. According to National Electrical Code, the pipe has to be bonded. However, it can be bonded using the grounding conductor serving the equipment that uses the gas.

Why does earth bond gas pipes?

Bonding is used to reduce the risk of electric shocks to anyone who may touch two separate metal parts when there is a fault somewhere in the supply of the electrical installation.

Does a gas boiler need to be earthed?

There is no requirement for bonding a boiler; it is earthed. Supplementary bonding is not required in a kitchen. However, this is a favourite with plumbers because they do not understand.

How do you ground a residential gas line?

Grounding means connection of a copper wire, often bare copper – to your gas line, then connecting the other end to your homes grounding system. National Electrical Code requires all homes to have a grounding system. This system consists of a ground rod (8′) driven in the ground close to your electric meter.

Article first time published on

Do gas meters need to be grounded?

Grounding and Bonding is one of the more involved sections of the electrical code. Things like gas piping don’t get “grounded” they get “bonded.” The meter itself isn’t required to be grounded or bonded.

Where do you bond the gas pipe?

Corrugated stainless steel tubing (CSST) gas piping systems shall be bonded to the electrical service grounding electrode system at the point where the gas service enters the building. The bonding jumper shall be not smaller than 6 AWG copper wire or equivalent.

How far should a ground rod be from a gas line?

The NEC requires all driven rods to be a minimum eight feet in the earth and for multiple connected rods a minimum spacing of six feet between rods.

How close can a ground rod be to a gas line?

It is supposed to be connected as close to the supply side as practical, preferably upstream of any cutoff valves. There should also be an electrical ground connection to your gas line if any of the gas lines inside the house are conductive, like black pipe.

Does gas pipe need to be bonded?

Bonding is required to prevent a possible electric shock hazard for persons that may be in contact with the gas piping and other grounded metallic building components. A stock hazard can result if these systems are energized at different levels of electrical potential.

Does flexible gas line need to be grounded?

CSST flexible gas piping must be bonded to reduce the risk of damage due to a lightning strike on the home.

What is difference between grounding and bonding?

Bonding is the connection of non-current-carrying conductive elements like enclosures and structures. Grounding is the attachment of bonded systems to the earth. Both are necessary to safeguard people and property from electric hazards.

How do you ground a gas furnace?

A common trick is to put a jumper on the ground on a grounded outlet. A common trick is to hook the neutral and ground together in the furnace and then physically connect the ground wire to the gas line.

Is Earth bonding a legal requirement?

The new requirement is for all electrical equipment in bath and shower rooms to be bonded together along with all metal pipework. Supplementary bonding connects to the earth wiring of the electrical equipment inside the bath or shower room. It must not be taken back to the main earth terminal in the consumer unit.

Can you bond gas and water together?

Depending on the route of the pipes, it would be permissible to bond the water pipe (at point of entry) as normal and then connect the gas pipe (at point of entry) to the water pipe at a convenient location; i.e. to use the water pipe as the bonding conductor for the gas. The other way round is not allowed.

Should central heating pipes be earthed?

Yes you need the earth bonding to the Gas and Water. Just install an RCD and don’t bother with the bathroom’s supplementary Bonding.

Do radiators need earthing?

However, the most important thing about the radiator is that it must be earthed, and this is what most users don’t know. Why bathroom radiator earthing is important is to prevent electrocution, fire hazards and damage to the radiator and other appliances.

What needs earth bonding in a house?

2 Answers from MyBuilder Electricians These should connect to 1) water installation pipes 2) gas installation pipes 3) other installation pipework and ducting 4) central heating and air con systems 5) exposed metallic structural parts of the building.

What kind of pipe do you use for natural gas underground?

Polyethylene gas piping systems are specifically engineered and certified for the underground environment.

What material is commonly used for gas piping in the house?

The most common materials used to make gas piping are steel, black iron, polyvinyl chloride (PVC), high-density polyethylene (HDPE) and copper. Some utilities prohibit some of these materials, so be sure to check with your local utility to determine what is allowed in your area before you install any.

How much does it cost to ground a Csst line?

How Much Does It Cost? As with most electrical repairs the cost can vary significantly based on many factors, but a good rule of thumb would be between $150 – $500 for most single-family homes in Central Iowa.

Do gas meters have a ground wire?

It is usually a #12 copper wire and we often see it wrapped loosely around the base of the gas supply pipe running up to the meter, as in the picture above. Gas companies also typically mandate that a warning tape be buried above the gas line to warn anyone digging there that an active gas line is below it.

What type of fitting is not permitted to connect a grounding system?

Grounding conductors and bonding jumpers shall be connected by exothermic welding, listed pressure connectors, listed clamps, or other listed means. Connection devices or fittings that depend solely on solder shall not be used.

What size wire do you need to bond a gas line?

The bonding conductor must not be smaller than a 6 AWG copper wire or the equivalent size if made of aluminum. The means for attaching the bonding conductor to the grounding electrode system must be in accordance with NFPA 70. The bonding conductor must be not longer than 75 feet (22,860 MM).

Does a ground rod have to be outside?

Ground rods need to be installed in the ground outside in a spot where they can be hammered 8 feet (2.4 m) into the ground.

Where should a grounding rod be placed?

A ground rod is usually located very close to your main electrical service panel and is often made of copper or copper coated steel. They’re approximately ½” in diameter and eight to 10 feet in length. It must be electrically tied to your main service panel to provide an approved ground connection.
