Stretch bolts also known as TTY bolts should be replaced each installation. … It is possible to reuse TTY bolts and some do without trouble. According to the manufacturers of the stretch bolts, there is a specification of a maximum length that the bolt can be stretched to before it becomes to week to rely on.

Can you use stretch bolts again?

stretch to ensure proper securing when tightened down. (Bolts with Specification: Torque plus Angle). Some of these bolts can be reused, if you torque them to the same torque that you would use for a normal bolt of the same size, pitch, lubrication factor, and strength rating.

What happens if you reuse TTY bolts?

However, because the tightening procedure does permanently stretch the bolt, there is some risk of breakage if the bolt is reused. And since there is no way to tell how many times a bolt has been reused, it doesn’t make any sense to reused TTY bolts – the risk far outweighs the replacement cost of used bolts.

How many times can I use stretch bolts?

Stretched Head Bolts Because of this, many standard head bolts are okay to use more than once, as long as they have not been stretched past their spring back point. Once this occurs, they should no longer be used in the engine, as they won’t clamp properly.

What happens if I Overtorque a bolt?

Fastener Torquing. Installing fasteners is an easy task (usually). To do so, you normally apply torque to the fastener, usually a nut or a screw head and simply “screw it in”. … As you can see in the picture to the right, if the fastener is over-tightened, the head is pulled beneath the surface of the wood.

Can you torque a bolt twice?

Double checking your torque is never a bad thing. By double clicking, you are allowing the fastener to rest for a second, then you are back at it to get the proper amount of torque there. This is the only other reason besides habit I can tell you why someone would do this.

Can cylinder head stretch bolts be reused?

A head bolt should not be reused if the threads are galled or badly damaged. … Chasing damaged head bolt threads with a die will clean up the threads but also remove material (metal) and undermine the head bolt’s ability to torque down and hold to specs.

What is the purpose of stretch bolts?

Stretch bolts for cylinder heads The clamping force of stretch bolts is necessary to retain the inevitable variations of cylinder head composite gasket material deformations due to heat etc. and they automatically keep the necessary clamping force on the head gaskets for them not to not leak.

Can you reuse torque to yield bolts?

Torque-to-yield (TTY) head bolts are designed to stretch when used. Once stretched, they are not as strong as before. Consequently, they cannot provide the same amount of clamping force and may break or shear off if reused.

Can you reuse head gaskets?

The reason behind this is: once the gasket is heat cycled, the embossments will not spring back to where they were originally. In a mock-up situation, it is perfectly acceptable to install, check clearances and reuse the gasket.

Article first time published on

Do bolts stretch when torqued?

To appropriately answer this question, it helps to first consider that only approximately 10-15% of the input torque actually stretches the bolt; the remaining 85-90% of input torque is primarily used to overcome friction between the mating threads and friction under the bolt head or nut.

How do you tell if a bolt has yielded?

Answer: Simply screw a nut on the previously used bolt’s thread to the head on a fully threaded bolt or to the thread runout on a bolt with a full diameter body. If a nut will not screw on the entire bolt thread length, the bolt has yielded and it is not safe to be reused.

Why do bolts snap?

Fatigue failure happens when the bolts have not been tightened properly, or have loosened up during its service life. If enough force is acting on the loosened joint during use of the product, bending stresses can weaken the fastener, eventually causing it to fail.

Should you tighten the nut or the bolt?

There is no simple answer to this as in some instances, it is perfectly acceptable to tighten the bolt head while holding the nut in place. In other situations, it’s acceptable to tighten the nut.

How many times can I reuse ARP head studs?

Generally bolts/studs that have a specific torque value to tighten to are reuseable, but bolts that you torque then turn an extra 1/4 turn or a number of degrees are torque to yield bolts and shouldn’t be reused more than once.

Should you replace head bolts when changing head gasket?

Head bolts should be replaced when you change the head gasket to prevent bolt failure. Restretching bolts isn’t a good practice. If the head bolts of your engine are the stretch type, they MUST be replaced when reinstalling the head(s). Stretch bolts are for one-time use only.

How can you tell if a bolt is TTY?

How are they identified? If a bolt is TTY, the final torque spec will list an angle in degrees rather than ft. -lbs.

How do you know if a bolt is one time?

For non-critical apps like the t/s cover, bolts can be reused. The best way to determine which is which is to look at the specified bolt torque in section 4 of the TIS workshop manual. If a bolt specifies a torque and an angle, it a TTY bolt. If it just specifies a torque, it’s reusable.

Can you overtighten with a torque wrench?

Over-tightening can cause damage to the fastener, and under-tightening can result in making the item you are attaching or assembling structurally weak and potentially unsafe for use.

Can you undo bolts with a torque wrench?

So long as users operate with caution and do not exceed the maximum torque, most torque wrenches can be used for undoing. … By exceeding the maximum torque limit during a bolt loosening you can affect the wrench accuracy, causing problems for future use. If in any doubt, use another tool for loosening bolts.

What is the advantage of torque to yield bolts?

Compared to conventional type bolts, torque to yield head bolts offer the engine manufacturer a number of advantages: greater flexibility of design. reductions in component costs. more accurate torque specifications.

Should I replace torque to yield bolts?

These bolts cannot and should not be reused due to the stress caused to the bolt during its first installation. … Torque-to-yield bolts may break if reused or become loose over time.

What grade is a bolt with 3 markings?

Three radial lines will indicate an SAE grade 5 fastener, while six radial lines will indicate an SAE grade 8 fastener.

What does tighten to yield mean?

A torque to yield fastener (TTY) or stretch bolt is a fastener which is torqued beyond the state of elasticity and therefore undergoes plastic deformation, causing it to become permanently elongated.

How do you remove torque from a yield bolt?

TORQUE-TO-YIELD BOLT REMOVAL TIPS * Place a punch in the center of each head bolt, then give each bolt a couple of raps with a hammer. The jarring action should help break loose any rust or corrosion between the threads on the bolts and those in the engine block.

What are stretch bolts made of?

Stretch bolts are made of steel which has a relativly long horizontal section of the load/ extension curve past the yield point. In use they are tightened by stretching them a specific amount, by measuring the rotation after the joint is nipped.

How many times can you use cylinder head bolts?

2. STRETCHED HEAD BOLTS. Bolts are designed to stretch as you torque them into place, and when you remove them, they snap back to their original position. Because of this, many standard head bolts are okay to use more than once, as long as they have not been stretched past their spring back point.

How do you reuse a metal head gasket?

As long as you have the head pulled, you might as well just put a new metal head gasket in there that you KNOW the thickness and condition of. you can reuse the metal headgasket. be sure that your head isn’t warped and it’s clean, sprays some copper gasket on to both side of the headgasket.

Can metal gaskets be reused?

Metal and malleable material gaskets (like are found in GM intake gaskets), can be reused if there isn’t any apparent damage to them. Even some MLS (multi-layered steel) head gaskets can be reused under the same conditions.

Should bolts be reused?

Reusing nuts, bolts, washers, and other mechanical fasteners is generally never a good idea. If you have any doubts about a fastener’s condition, it is best to discard it in favor of new fasteners as that will always result in a stronger, more durable joint.

How much does a bolt stretch?

For example, a 3/4″ UNC grade 5 bolt with a 3” clamp distance, fully tightened, only stretches the bolt approximately 0.006”. This stretch creates 21,300 lbs clamping force.
