There is only one Ze which is at the origin of the supply. The board fed by the sub main will have a Zs value at the board which will roughly equal Ze = R1 +R2. You measure the Zs at the incomming terminals of the sub board. This is sometimes also called Zdb.

How do you calculate ZS from Ze?

Therefore, where reliable measured values are available for the external earth loop impedance (Ze) and for the loop resistance of the line and protective conductors (R₁ + R₂) of the circuit, it is permissible to derive the loop impedance of a circuit by using the following formula: Zs = Ze + (R₁ + R₂).

What is ze value?

`Ze` is a measurement of the external earth fault impedance of the installation. It is the measured resistance of the supply transformer winding, the supply phase conductor, and the erath return path of the supply. `Ze` can be obtained by enquiry to the electricity supplier or by direct measurement at the supply.

Is Ze the same as ZDB?

Comlec Screwfix Select. Where a DB is fed from the installation origin then the Ze and Zdb are essentially the same. If a switch fuse was added and the DB located elsewhere then the Zdb would be slightly different.

How do you calculate Ze?

Ze =R1 + R2.

What is the maximum Ze for a TT system?

The IEE recommended figure for external loop impedance (Ze) for a T-T system is up to 200O although current standards define a higher maximum value. … The IEE recommended figure for external loop impedance (Ze) for a T-T system is up to 200Ω although current standards define a higher maximum value.

What happens if Zs is too high?

Zs represent earth fault loop impedance and consists of Ze and (R1+R2). … If Zs are too high, not enough fault current can flow and the MCB may not trip at all. On circuits after 17th edition, RCDs will be more common and will trip before MCBs.

What is R1 and R2?

For ring circuits, the resistance along the length of the ring is measured for each of the live (r1), earth (r2) and neutral cables (rn). This will show any break in the ring, or any junction where the resistance is high, for example where a cable is not properly joined.

What is the maximum ZS permitted by bs7671?

​The 1.37 ohms value is the 100% max Zs value which should be recorded on the test certificate.

What does ZS mean in electrical?

Earth fault loop impedance (Zs) is the impedance in ohms of the circuit path formed during a fault between earthed metal work and live parts. It includes the external impedance circuit (Ze) and the resistance of the phase and circuit protective conductors (R1 + R2).

Article first time published on

What is a good earth loop impedance?

The value of external earth loop impedance (Ze) measured or otherwise determined in accordance with Regulation 313.1 may differ from the applicable typical maximum value declared by the electricity distributor, which is usually: 0.8 Ω for TN-S system. 0.35 Ω for a TN-C-S system.

Is R1 a ZS R2?

R1+R2 = Circuit Resistance. Zs = Circuit Earth Fault Loop Impedance. Ze = External Earth Fault Loop Impedance.

How do you calculate Zs on a TT system?

Technical discussion forums·Wiring and the regulations·Other and general engineering discussionsArchived categories

How does Mccb calculate max Zs?

Max Zs for 60974-2 MCCB The Cmin factor is 230 x 0.95 = 218.5 volts, therefore to calculate Zs: 230 x 0.95 = 218.5, 218.5 / la = Zs.

What is the maximum trip time for an RCD?

What is the maximum allowable tripping time? A common misconception is that RCDs must trip in 30 ms. In fact, an RCD when tested at its rated sensitivity must trip in 300 ms. When tested at five times, ie, 150 mA for a 30 mA device, it should trip in 40 ms.

Why is ZS important?

If the wrong type of RCD is used, it may not operate effectively under certain types of equipment fault, hence will not disconnect, again we are now relying on the mcb or fuse, and hence the Zs value is important.

What's the max Zs on a TT circuit?

The maximum disconnection times for a TT system is 0.2 seconds for final circuits up to and including 32A (Table 41.1) and for distribution circuits or circuits greater than 32A it’s 1 second (411.3. 2.4).

When would you use a 100mA RCD?

The manufacturers seem to be saying that 30mA RCD protection is preferable but 100mA is acceptable if nuisance tripping occurs. So you would be complying with their instructions. The manufacturers seem to be saying that 30mA RCD protection is preferable but 100mA is acceptable if nuisance tripping occurs.

Can I use RCBO on TT system?

A simple answer is ‘don’t use RCBOs in a TT installation‘, but RCBOs are really useful.

What are Zs values?

Zs = Ze + (R1 + R2) – Zs is the earth fault loop impedance (Ω) – Ze is the measured value of external impedance (Ω), and. – (R1 + R2) is the measured value of resistance (Ω) for the line conductor and protective conductor, at the most distant point or accessory from the distribution board or consumer unit.

Do you double Pfc on 3 phase?

For three phase installations test each phase separately and double the measured reading (test between Line 1 and Neutral, then Line 2 and Neutral and last Line 3 and Neutral). Some test meters require that the third (usually green) lead to be connected on the Neutral during this test.

What is the maximum r1 r2?

Technical discussion forums·Wiring and the regulations·Other and general engineering discussionsArchived categories

How do you calculate r1 r2 in ring final circuit?

Using the low reading ohm meter, test between Line and Earth on every outlet on the ring circuit. The highest reading is the (R1+R2) for the circuit. The readings at each of the sockets wired on the ring should be very similar and the value should be according to this formula: (r1 +r2)/4.

What does ZS Ze +( R1 R2 mean?

R1 is the resistance of Circuit Phase conductor and R2 is the resistance of Circuit Earth Conductor Ze is the External ( supply ) Impedance of earth fault current path (loop) to Earth Zs is the total Impedance of earth fault current path (loop) to Earth. Zs = Ze + (R1 + R2 )
